140097-1: Print

Onderdelenlijst
Weerstanden
R1,R4 = 68 k
R2,R5,R6 = 10 k
R3,R9,R10,R12 = 100 k
R7 = 2,2 k
R8 = 2,2 M
R11 = 1 M
R13 = 1,2 k
R14 = 10 Ohm
P1,P2,P3 = 500 k trimpotmeter
P4 = 1 M trimpotmeter
P5 = 10 k potmeter, logaritmisch
Condensatoren
C1,C10 = 1 µ, 50V
C2 = 10 n
C3 = 100 n
C4 = 47 µ, 50V
C5,C6 = 100 µ, 50V
C7,C11 = 220 µ, 50V
C8,C9,C12 = 10 µ, 50V
C13 = 47 n
Halfgeleiders
D1,D2,D3 = 1N4148
IC1 = MAX660
IC2 = LM324
IC3 = LM386
T1,T2 = 2N3904
T3 = BC547C
Diversen
K1 = USB-B-connector
K2 = 2-pens pinheader, steek 2,54 mm
Print # 140097-1
